For the purpose of these guidelines, development projects in the coastal zone may be classified into four broad types:-
- Shore front development
- Back shore development
- Land reclamation
- Sand mining and river mouth dredging.
|
| 3.1 |
SHORE FRONT DEVELOPMENT PROJECTS |
| 3.1.1 |
Preamble |
| |
Shore front development projects are those projects located on the shoreline or foreshore such as the construction of ports, marinas, breakwaters, groynes, jetties, causeway, bridges, undersea tunnels, sewerage outfalls, and laying of submarine cables and pipelines. These development projects can interfere with the equilibrium of natural coastal processes which may result in coastal erosion/siltation problems, damage to marine eco-systems, aquaculture systems and water pollution, although the severity of the adverse impacts may differ from one case to another. Hence they should be subjected to proper impact evaluation study using appropriate technology commensurate with the nature and scale of the development project.
|
| |
|
| 3.1.2 |
Activities Captured Under Environmental Impact Assessment |
| |
Order 1987 (EIA)
Some of the above activities are captured under the purview of the Environmental Quality Act, 1974 Environmental Quality (Prescribed Activities) (Environmental Impact Assessment) Order 1987 such as:-
|
| |
- Activity 8 (f) - Construction of shipyard with dead Weight Tonnage greater than 5,000 tones;
- Activity 10 (a) - Construction of ports and port expansion involving an increase of 50% or more in handling capacity per annum;
- Activity 12 - Construction of Petroleum related activities such as construction of oil refineries (Activity 12 (d)) and construction of off-shore and on-shore pipelines in excess of 50 km in length (Activity 12 (b));
- Activity 13 (d) - Construction of power generation and transmission facilities such as construction of combined cycle power stations;
- Activity 18 (c) (ii) - Construction of marine outfall
|
| 3.1.3 |
Scope of Impact Evaluation Study |
| |
For shore front development projects, the study for coastal engineering works done for the purpose of Administrative Circular No. 5 of 1987 can also be used for the purpose of EIA review. For coastal engineering works a comprehensive impact evaluation study should typically include; |
| |
- preparation of key plan, location plan and site plan showing the siting and layout of proposed development or engineering works as outlined in paragraph 2.1 above;
- topographic, hydrographic, natural and physical conditions of the project site and its vicinity as outlined in paragraph 2.1 above as well as the existing socia-economics conditions;
- determination of the local wave climate, current, tides, storm surge, and sediment characteristic;
- study of historical information to determine the trends and rates of accretion and erosion;
- prediction or measurement of the movement of sediment, littoral transport, sediment budget analysis under the without and with project assumptions;
- determination of the immediate and long term influence of the proposed development works on the neighbouring sections of the coastlines and future trends. This should include quantitative estimation of shoreline changes such as erosion and accretion and their socioeconomic implication;
- evaluation of environmental impact with regard to all of the uses of the shoreline/estuaries such as aquaculture, fishing activities, recreation including potential impacts on water quality and marine ecology; and,
- identify, describe and map feasible mitigative measures to overcome the various adverse effects arising from (f) and (g) above. This should cover capital works as well as the operation and maintenance measures, where applicable.
|
| 3.1.4 |
Use of Computer Modelling |
| |
- For the larger and more complex projects, physical and/or computer modelling studies are strongly recommended. Computer models, however, are less time consuming and more suitable for problems involving coastal sediment transport. For some projects, it may be possible to resort to expert opinions of experiences coastal engineers for a preliminary impact assessment and to decide on the need and/or scope of more detailed modelling studies.
- Where computer models are used in the analysis, they must be proven or well-tested. In addition, proper attention must be given to data collection, model calibration and verification. All raw data and boundary conditions must be clearly stated and made available to enable the Coastal Engineering Technical Center (CETC), Department of Irrigation and Drainage to verify the model predictions by similar or independent means. It is advisable that the Consultant have prior consultation with CETC regarding the acceptability of a particular computer software for project-specific applications.
|
| 3.1.5 |
Other Guidelines |
| |
The other guidelines for shore front development activities are:- |
| |
- for the construction of jetties, bridges and causeway, an open piling system is preferred over solid barriers because the latter could interfere with the continuity of littoral sediment transport;
- the use of vertical faced shore front protection works (for example sea wall) is not encouraged; and
- sewage outfall pipes should be extended to beyond the Mean Low Water Spring (MLWS) and buried with a minimum cover of 1 metre to avoid any obstruction to the littoral drift. Likewise submarine cable and pipelines should also be buried with a minimum cover of 1 metre along the entire stretch.
|
| 3.1.6 |
Flow Chart |
| |
The flow chart for the processing of shore front development projects
is as shown in Figure 1. |
|
|
| 3.2 |
BACK SHORE DEVELOPMENT PROJECTS |
| 3.2.1 |
Preamble |
| |
Back shore development projects include works such as construction of hotel, housing, agricultural and industrial development. These projects, by far represent the bulk of economic development activities in the coastal zone. |
| 3.2.2 |
Activities Captured Under Environmental Impact Assessment Order 1987 |
| |
Some of the back shore development activities that are captured under the Environmental Quality Act, 1974 Environmental Quality (Prescribed Activities) (Environmental Impact Assessment) Order 1987 are:- |
| |
- Activity 7 - Housing development covering an area of 50 hectares or more; and,
- Activity 17(a) - Resort and recreational development such as construction of coastal resort facilities or hotel with more than 80 rooms.
|
| 3.2.3 |
Scope of Impact Evaluation Study |
| |
The impact of such projects can be wide-ranging. In the case of projects involving extensive clearing of vegetation, backfilling of land and bunding and construction of inland lagoon, full impact evaluation studies along the lines of paragraph 3.1.3 and 3.1.4 would be required. However, in cases comprising of small scale housing, resort and industrial development, it is advised that such development be sited at a suitable distance from the shoreline (development setback) to minimise the risk of damage or losses due to coastal erosion and undue interference on the near shore biological and marine environment. If this is complied with, an impact evaluation study (on the coastal erosion aspect) is not necessary. It is, however, cautioned that the need for an environmental impact study is still required by the Department of Environment if it falls within the purview of Environmental Quality Act, 1974 Environmental Quality (Prescribed Activities) (Environmental Impact Assessment) Order 1987 (for example Activity 17 (a)) or Natural Resources and Environment Ordinance (Sarawak). |
| 3.2.4 |
Setback Limits |
| |
a. The following setback limits are proposed:- |
| |
- 60 metres for sandy coast measured from Mean High Water Line; and,
- 400 metres for muddy coast measured from the seaward edge of mangrove vegetation/forest. However, no development should be allowed in areas where mangrove vegetation/forest have been gazetted as permanent forest reserve under the national Forestry Act 1984.
|
| |
b. Where beach dunes are present, they should be preserved in their natural state. New development or re-development activities on sand spits and sandbars should not be permitted. |
| |
c. The above setback limits are not entirely dependent on the current stability of the coastline or classification of erosion hazard (critical, significant or acceptable). They are considered as good management/engineering practices for shoreline development in recognition of the dynamic nature of coastal processes and the potential risk of shoreline erosion which requires substantial funds for their redressal. |
| |
d. The minimum setback requirements may be reviewed on account of site specific conditions. Examples of conditions warranting such review are:- |
| |
- where it is within 1 km of a well developed area with high value permanent buildings located at distances less than the recommended setback;
- where the proposed development is landward of an existing public access for example Public Works Department (JKR) road or coastal bund, the loss or failure of which is unacceptable;
- where the developer undertakes to provide coastal erosion protection works based on a design acceptable to the government;
- where the prevailing backshore is an erosion -resistant headland; and,
- where the developed area is on high ground at levels exceeding five metres above the Mean Sea Level
- where turtle nesting site facilities are required.
|
| 3.2.5 |
Other Guidelines |
| |
For development projects sited in critical erosion areas, the developers shall be required to construct feasible erosion protection works at their own cost. The use of vertical faced shore front protection works (for example sea wall) is not encouraged. |
| 3.2.6 |
Flow Chart |
| |
The flow chart for processing backshore development projects is as shown in Figure 2. |
| 3.3 |
LAND RECLAMATION |
| 3.3.1 |
Preamble |
| |
The potential impact of a reclamation project is governed by a number of factors such as its location, wave and tidal regime, size and the geometrical planform of the reclamation area. In this respect, hydraulic study/modelling is a useful tool for optimising the layout of large-scale reclamation works and in identifying potential adverse impact. Piece-meal reclamation involving uncoordinated effort of a large number of small, individual land owners is highly undesirable because it often result in a highly irregular coastline which is difficult to manage from the viewpoints of coastal erosion control and for recreational use of the beach. Some typical impacts of coastal land reclamation projects are:- |
| |
- complete or partial loss of recreational beaches and undue obstruction of public access to these beaches;
- interference with the normal coastal processes resulting in erosion of coastlines or siltation of natural or man-made drainage channels;
- lack of effective works for protection against coastal erosion;
- interference with the natural drainage of hinterland areas;
- destruction of mangrove eco-systems and other environmental habitat for flora and fauna;
- pollution of coastal waters; and,
- complete or partial loss of aquaculture and fishing activities and access to fish landing sites.
|
| 3.3.2 |
Scale of Reclamation Captures Under Environmental Impact Assessment Order 1987 |
| |
Coastal reclamation involving an area of 50 hectares or more is captured under Activity 4 of Environmental Quality Act, 1974 Environmental Quality (Prescribed Activities) (Environmental Assessment) Order 1987 where an EIA study is mandatory under the law. |
| 3.3.3 |
Scope of Impact Evaluation Study |
| |
However, all land reclamation projects irrespective of paragraph 3.3.2 should be subjected to impact evaluation studies as detailed in paragraphs 3.1.3 and 3.1.4 above. The impact assessment should capture the hydrodynamics and morphological changes using a modelling approach. |
| 3.3.4 |
Provision of Drainage facilities to The Hinterland |
| |
There should be proper provisions for discharging the drainage or flood flows of the hinterland catchment intercepted by the reclamation landfill. |
| 3.3.5 |
Setback Limits |
| |
For the reclaimed shoreline, there should be a setback of 60 metres measured from the landward edge of the Mean High Water Spring. However, if coastal erosion protection works are provided, the developer need to provide a sufficient setback to be agreed upon by the CETC for the maintenance of the structures. This setback zone should also be equipped with a service road built by the developer for public access to sea frontage. |
| 3.3.6 |
Flow Chart |
| |
The flow chart for processing land reclamation projects is as shown in Figure 3. |
|
|
| 3.4 |
OFFSHORE SAND MINING AND RIVER MOUTH DREDGING |
| 3.4.1 |
Preamble |
| |
Offshore sand mining activities change the bathymetry of the sea bed which can alter beach dynamic, waves and swell patterns, as well as coastal current circulation, which may lead to erosion or sedimentation. Mining activities can influence the coastal processes through:- |
| |
- erosion of beaches from drawdown due to the backfilling of the dredge pit during calm period;
- interception of sediment movement by the dredged pit, which results in sand depletion onshore or downdrift;
- removal of protection afforded by offshore banks, which leads to bigger waves impinging on the coast;
- changes in the waves refraction pattern, which concentrates waves energy at a particular place; and
- destruction of aquatic eco-systems and adverse effects on aquaculture systems.
|
| 3.4.2 |
Federal and State Jurisdiction |
| |
The approval for sand mining falls under the purview of either the Federal or State jurisdiction, depending on the location of the operation. All land, including the foreshore up to 3 nautical miles seaward from the low-water mark, is controlled by the state. The seabed and water beyond this limit, up to the continental shelf boundary, falls under federal jurisdiction. Under Emergency (Essential Powers) Ordinance No. 7/1969, the territorial sea is extended to 12 nautical miles measured from the low-water mark, in all states except Sabah and Sarawak. This law applies for all purposes except for those covered under the Continental Shelf Act (1966), the Petroleum Mining Act (1966), the National Land Code (1965) and written laws relating to land in Sabah and Sarawak.
|
| 3.4.3 |
Sand Mining Activities Captured Under Environmental Impact Assessment Order 1987 |
| |
Sand mining activities involving an area of 50 hectares or more are captured under Activity 11 (c) of Environmental Quality Act, 1974 Environmental Quality (Prescribed Activities) (Environmental Impact Assessment) Order 1987. |
| 3.4.4 |
Additional Data Requirement |
| |
In addition to the data requirement as stated in paragraph 2.1, the following information/reports are also required to be submitted to enable the application to be processed:- |
| |
- the location on a hydrographic chart of the sand source where the project proponent intends to mine;
- site investigation report on the availability of the sand source;
- quantity of sand to be mined per month and per year; and
- the sequence/procedure of sand mining and the equipment/machinery to be used.
|
| 3.4.5 |
Guidelines For Sand Mining |
| |
As a general rule, sand mining is not permitted in nearshore areas which are less than 1.5 km from the Mean Low Water Line or 10 metre water depth (from Lowest Astronomical Tide) whichever is further from the shore. This is to ensure that this will not result in any major disruption to the delicate balance of sediment movement in the nearshore littoral cell.
If it is not possible to comply with the para above due to technical, practical or economic reasons, a suitable study as outlined in paragraphs 3.1.3 and 3.1.4 should be conducted to demonstrate that the proposed site of sand mining operation would not lead to adverse impacts on the coastal processes, aquatic eco-systems and the stability of the adjacent shorelines. Not withstanding the above, if there is an existing study which shows that any sand mining activity in a particular area will have adverse impacts, all mining activities in these sensitive areas shall be prohibited even if the general guidelines for sand mining have been adhered to. |
| 3.4.6 |
River Mouth Dredging |
| |
Dredging or deepening of natural river mouths may result in the creation of sediment sinks leading to problems of erosion in adjacent coastlines. As such sand mining at river mouth or sandspit for commercial uses without proper hydraulic study as outlined in paragraph 3.1.3 and 3.1.4 shall be prohibited. |
| 3.4.7 |
Flow Chart |
| |
The flow chart for processing sand mining application is as shown in Figures 4 and 5. |
